TCR-225

TCR-225


The TCR-225 thermal window wall system is available dry-glazed and as a pre-glazed system to minimize field labor. It provides a visually seamless aesthetic and exceptional thermal performance.

  • • Innovative front screw spline, allowing for tight, more consistent joints.
  • • Available in dual-finish for customized exterior and interior finish
  • • 5” depth x 2-1/4” face dimension
  • • Available Field Glazed or Pre-glazed
  • • Inside and Outside Glazing Options

Meet the new standard in thermal window walls. TCR-225 combines seamless design with unsurpassed efficiency, weathering tough environments, installing with ease and saving you on glass costs, to keep you on budget. TCR-225 is available dry-glazed and as a pre-glazed system, significantly reducing field labor costs and making installation easier, allowing you to stay on schedule and on budget. Our proprietary triple hollow thermal strut provides exceptional thermal performance to achieve industry-leading U-Factors without triple glazing. An innovative front screw spline provides tight, more consistent joints, eliminating visual gaps between horizontal and vertical mullions for a flawless window wall. Dual finish options allow for customized aesthetics.

  • • Innovative front screw spline, allowing for tight, more consistent joints.
  • • Available in dual-finish for customized exterior and interior finish
  • • 5” depth x 2-1/4” face dimension
  • • Available Field Glazed or Pre-glazed
  • • Inside and Outside Glazing Options
  • • SSG Mullion and SSG intermediate horizontal Option
  • • Standard Captured Corners (90° and 135°)
  • • Slab edge conditions
  • • Door Sub-Frame options
Show Less
Select File Type...
  • • Air Infiltration – <0.06 cfm/ft2 at 6.24 PSF per AAMA 501, ASTM E283
  • • Static Water – 12 PSF per AAMA 501, ASTM E3311
  • • Dynamic Water – 12 PSF per AAMA 501, AAMA 501.12
  • • U-Factor as low as 0.30 (COG=0.24) per NFRC 100
  • • CRF (frame) up to 74 per AAMA 1503
